Extra Triple Protection BMS & Low Temp Cut-off
- SUPER EMPOWER strive for higher quality; SUPER EMPOWER’s 12.8V 100Ah LiFePO4 battery is optimized for trolling motor users with its BMS featuring triple protection against dust, water, and salt spray, as well as 100% full protection against overcharging, over-discharging, over-current, overheating, and short circuits. And it is upgraded with a low-temperature cut-off function to ensure safe use in low-temperature environments. Designed for harsh environments such as rainy or marine, or dusty and wet conditions, this battery offers worry-free and long-lasting performance with an extended lifespan.
Marine Batteries Specially Designed for Trolling Motor
- SUPER EMPOWER goes beyond standard and is committed to innovation. The advanced built-in TVS provides superior protection against voltage spikes and surges for upgraded shock resistance, ensuring your battery and motor remain stable and protected in the rough waters. Whether you’re trolling for big fish or cruising for leisure, the 12.8V 100Ah (Trolling Motor) LiFePO4 battery gives you the confidence to enjoy your time on the water to the fullest. It’s also for Yacht, Marine, Boat, RVs,Vans, Motorhomes, Home Energy, Solar Power Storage, Off-Grid Solar Power System, Backup Power, etc.
Perfect Replacement for Lead-acid Batteries
- SUPER EMPOWER’s 12.8V 100Ah lithium battery uses Grade A LiFePO4 cells for exceptional quality, higher energy density, and greater power, certified by UL testing for highest level of safety. The 12.8V 100Ah LiFePO4 battery has an impressive 5-year lifespan, with 4000+ cycles @100% DOD (6000 cycles @80% DOD, 15000 cycles @60% DOD). In contrast, Lead-acid/SLA/AGM batteries typically only last for 3 years with 200-500 cycles, it can perfectly replace lead-acid batteries.
Auto Overload Protection & Recovery
- Say goodbye to manual intervention due to battery shutdown or protection mode. The 12.8V 100Ah LiFePO4 battery features automatic overload recognition, protection and recovery, allowing the battery to self-protect and resume normal operation in case of an overload.
Expandable for Wide Applications
- Expandable up to 4 in series and 4 in parallel (Max 4S4P), the 12.8V 100Ah LiFePO4 battery can build a 48V 400Ah system for max. 20.48kWh energy and 20.48kW load power. Perfect for RV, solar, home energy storage, and especially ideal for 30-70 lb thrust trolling motors.
12V Lithium Battery 100AH Brief Specifications
Operating Voltage
12.8V
Charging Voltage
14.4±0.2V
Recommended Charge Current
20A (0.2C)
Max Continuous Discharge Current
100A
Max. Continuous Output Power
1280W
12V Lithium Battery 100AH Precautions for Use
First, when connecting in series or parallel, ensure that the batteries are identical in brand, type, voltage, capacity, and BMS, and that they were purchased within 1 month. Second, if OT terminals are secured directly with screws and their thickness is less than 2mm, use gaskets to lock them in place to prevent loosening and overheating. This also applies to clamps.
12V Lithium Battery 100AH Resources/Downloads
Key Benefits of 12V Lithium Battery 100AH
Versatile and Durable
Low voltage protection prevents over-discharge and cell damage.
Lighter and Compact
High-energy density lithium-ion battery provides more power than lead-acid batteries.
Scalability
Modularity is a key factor for easy expansion.
Extended Lifespan
Up to 6,000 charging cycles compared to the 500 cycles of lead-acid batteries.
Faster Charging
A higher charge acceptance rate allows the batteries to recharge quickly.
